Chemical Powder Fixed Bin Blender

FOB Reference Price:Get Latest Price
$5,000.00 - $50,000.00 / Units | 1 Unit/Units (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Model Number:
TFB-300L
Max. Loading Capacity:
3000L
Condition:
New
Mixer Type:
Other
Product Type:
Other
Application:
Powder
Additional Capabilities:
Other
Place of Origin:
Shanghai, China
Brand Name:
TANDY
Voltage:
3P AC208-415V 50/60HZ
Dimension(L*W*H):
1850*1300*2000MM
Certification:
CE
Name:
Chemical Powder Fixed Bin Blender
Material:
Contact part SS304
Max bin volume:
300L
Max working volume:
240L
Max charge weight:
150kg
Turning speed:
3-20
Total weight:
600kg
Total power:
1.5kw
After-sales Service Provided:
Engineers available to service machinery overseas
Warranty:
One Year
Power(W):
1.5KW
Supply Ability
Supply Ability:
30 Unit/Units per Month
Packaging & Delivery
Packaging Details
Chemical Powder Fixed Bin Blender Of Packaging Detail:
Export Wooden Case
Port
Shanghai port
Lead Time :
The normal shipped in 60 days after receive the advance payment
Product Description



The machine is composed of machine base,driving system,control system,mixing hopper,etc.when it works,after materials are fed into the hopper,lock the hopper cover,set the mixing time and mixing speed according to the process requirement.start the control system to start the mixing operation.When the set time is reached.the machine will stop automatically.after mixing is finished.carry out material distribution.



Main Features

1. The machine effectively controls dust pollution and cross contamination,reduces loss of material,controls material layering,optimizes production processes,and fully meets the requirements for medicine production in GMP.



2. The gyrator(mixing hopper)forms an included angle of 30 with the rotation axis.The materials in the mixing hopper rotate along with the gyrator and make tangential movement and achieving the best mixing effect.



3. PLC automatic control is adopted.It is provided with the infrared safety device and the discharging butterfly valve with the misoperation preventer to ensure safe production.



Company Information

Shanghai Tandy Machinery Manufacturing Co.Ltd. is devoted in machine manufacture;we are specialized in development,production and related service for mixer blender,conveyor equipment,dust precipitation and so on.We derive advanced technology both at home and abroad,realize the innovation and breakthrough in technology;our products are widely application in industry of food,chemical,pesticide,dyestuff,metallurgy,feedingstuff etc.We adhere to"trust,quality,overstep"corporation culture,would like to grow up together with customers and partners to make concerted efforts,common development.

Packaging & Shipping



Our Services



Pre-service:
1.Inquiry and consulting support.
2.Sample testing support.
3.View our Factory.
4.Make plans for choice according to the needs and special requirements of users in different sectors;

Sale service
1. Ensure product with high quality and pre-commissioning before delivery;
2. Delivery on time;
3.Provide full set of documents as customer’s requirements.

After-sale service
1 .advisory services: users encounter any problems in the use process, can call the company for technical support
2.warranty: warranty period of the product, if quality problems, the company responsible for the warranty service.
The user from the date of purchase, under normal circumstances if the product quality problems:
1. complete within one year free warranty,three years repair finite maintenance.
2. component damage free warranty for 1 years.
